| CAT# | SIZE | INSIDE DIAMETER | OUTSIDE DIAMETER | BEND RADIUS | PKG | ||
| MIN. | MAX. | MIN. | MAX. | MIN. | |||
| inch | mm | mm | mm | mm | mm | m/roll | |
| PFC10 | 1/4" | 9.7 | 10.4 | 14.4 | 14.7 | 45 | 100 |
| PFC13 | 3/8" | 12.3 | 12.8 | 16.7 | 17.2 | 50 | 100 |
| PFC16 | 1/2" | 15.8 | 16.3 | 20.2 | 20.7 | 65 | 50 |
| PFC21 | 3/4" | 20.7 | 21.2 | 25.5 | 26.1 | 75 | 50 |
| PFC26 | 1" | 26 | 26.6 | 31.6 | 32.2 | 100 | 50 |
| PFC34 | 1-1/4" | 34.7 | 35.4 | 40.8 | 41.5 | 125 | 25 |
| PFC40 | 1-1/2" | 40 | 40.6 | 46.6 | 47.2 | 150 | 25 |
| PFC051 | 2" | 51.3 | 51.9 | 58.1 | 58.7 | 175 | 20 |
| PFC063 | 2-1/2" | 63 | 63.6 | 71.8 | 72.4 | 200 | 10 |
| PFC078 | 3" | 78 | 78.7 | 87.2 | 87.9 | 225 | 10 |
| PFC101 | 4" | 101.6 | 102.6 | 111.2 | 112.3 | 275 | 10 |
| PFC125 | 5" | 125 | 127 | 137 | 139.5 | 300 | 5 |
| PFC150 | 6" | 150 | 153 | 162 | 165 | 400 | 5 |
