| CAT# | SIZE | INSIDE DIAMETER | OUTSIDE DIAMETER | BEND RADIUS | PKG | ||
| MIN. | MAX. | MIN. | MAX. | MIN. | |||
| inch | mm | mm | mm | mm | mm | m/roll | |
| GFC10 | 1/4" | 9.7 | 10.2 | 13.5 | 14 | 40 | 100 |
| GFC13 | 3/8" | 12.3 | 12.8 | 15.7 | 16.2 | 50 | 100 |
| GFC16 | 1/2" | 15.8 | 16.3 | 19.2 | 19.7 | 65 | 50 |
| GFC21 | 3/4" | 20.7 | 21.2 | 24.5 | 25.1 | 75 | 50 |
| GFC26 | 1" | 26 | 26.6 | 30.4 | 31 | 100 | 50 |
| GFC34 | 1-1/4" | 34.7 | 35.4 | 39.6 | 40.3 | 125 | 25 |
| GFC40 | 1-1/2" | 40 | 40.6 | 45.2 | 48.8 | 150 | 25 |
| GFC051 | 2" | 51.3 | 51.9 | 56.5 | 57.1 | 175 | 20 |
| GFC063 | 2-1/2" | 63 | 63.6 | 70.2 | 70.8 | 200 | 10 |
| GFC078 | 3" | 78 | 78.7 | 85.2 | 85.9 | 225 | 10 |
| GFC101 | 4" | 101.6 | 102.6 | 108.5 | 109.5 | 275 | 10 |
| GFC125 | 5" | 125 | 127 | 135 | 137 | 300 | 10 |
| GFC150 | 6" | 150 | 153 | 160 | 162 | 400 | 5 |
